RICOH skener Fi-7800 A3, color, duplex, 110ppm v barvě 300dpi, USB 2.0, ADF 500, Z: 12M
Popis a parametry
RICOH skener Fi-7800 A3, color, duplex, 110ppm v barvě 300dpi, USB 2.0, ADF 500, Z: 12M
https://www.pfu.ricoh.com/global/scanners/fi/fi7800/
| Product Name | fi-7800 | |
|---|---|---|
| Scanner Type | ADF (Automatic Document Feeder) / Manual Feed, Duplex | |
| Scanning Speed*1 (A4 Landscape)(Color*2/Grayscale*2/Monochrome*3) | Simplex: 110 ppm (200/300 dpi) Duplex: 220 ipm (200/300 dpi) | |
| Scanning Speed*1 (A4 Portrait)(Color*2/Grayscale*2/Monochrome*3) | Simplex: 90 ppm (200/300 dpi) Duplex: 180 ipm (200/300 dpi) | |
| Image Sensor Type | Color CCD x 2 (front x 1, back x 1) | |
| Light Source | White LED Array x 4 (front x 2, back x 2) | |
| Optical Resolution | 600 dpi | |
| Output Resolution*4 (Color / Grayscale / Monochrome) | 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)*5 | |
| Output Format | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit | |
| Background Colors | White / Black (selectable) | |
| Document Size | Maximum | 304.8 x 431.8 mm (12 x 17 in.) |
| Minimum | 52 x 74 mm (2 x 3 in.) | |
| Long Page Scanning*6 | 5,588 mm (220 in.) | |
| Paper Weight (Thickness) | A4 to A5 Size | 20 to 209 g/m2 (5.4 to 56 lb) |
| Less than A5 Size / Over A4 Size | 41 to 209 g/m2 (11 to 56 lb) | |
| ADF Capacity*7 | 500 sheets (A4 80 g/m2 or Letter 20 lb) | |
| Expected Daily Volume*8 | 100,000 sheets | |
| Multifeed Detection | Overlap detection (Ultrasonic sensor), Length detection | |
| Paper Protection | Lag detection | |
| Interface | USB 2.0 / USB 1.1 | |
| Power Requirements | AC 100 to 240 V ±10 % | |
| Power Consumption | Operating Mode | 200 W or less |
| Sleep Mode | 3.2 W or less | |
| Auto Standby (Off) Mode | Less than 0.3 W | |
| Operating Environment | Temperature | 5 to 35 °C (41 to 95 °F) |
| Relative Humidity | 20 to 80% (Non-condensing) | |
| Environmental Compliance | ENERGY STAR, RoHS | |
| Dimensions*9 (W x D x H) | 460 x 430 x 310 mm (18.1 x 16.9 x 12.2 in.) | |
| Weight | 32 kg (70 lb) or less | |
| Supported Operating System | Windows 11*10, Windows 10*10, Windows Server 2025, Windows Server 2022, Windows Server 2019, Windows Server 2016 | |
| Software / Drivers*12 | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS™), WIA Driver*11, PaperStream Capture, PaperStream ClickScan, Software Operation Panel, Error Recovery Guide, PaperStream Central Admin | |
| Image Processing Functions | Multi image output, Automatic color detection, Blank page detection, Static threshold, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Cropping, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Character extraction, Background pattern removal, Automatic profile selection | |
| Included Items | AC cable, USB cable, Setup DVD-ROM | |
.
ParametryPorovnání
Funkce
Automatické oboustranné skenování
Typ skeneru
Průtahový
Skutečné rozlišení skeneru (v DPI)
600
Rozhraní
USB
Formát
A3
Automatický podavač dokumentů
Ano
