HPE PL DL380g10 Plus 4309Y (2.8/8C) 32G MR416i-p 8SFFU3 1x800W 2x10G SFP+ ocp
HPE PL DL380g10 Plus 4309Y (2.8/8C) 32G MR416i-p 8SFFU3 1x800W 2x10G SFP+ ocp
HPE PL DL380g10 Plus 4309Y (2.8/8C) 32G MR416i-p/4Gssb 8SFFU.3 1x800Wti L9 2x10GSFP+ocp RF
| SKU Number | P55278-421 |
| Model Name | HPE ProLiant DL380 Gen10 Plus 4309Y 2.8GHz 8-core 1P 32GB-R MR416i-p NC 8SFF 800W PS EU Server |
| Chassis | 8SFF |
| Backplane | 8SFF x1 Tri-Mode 24G U.3 BC |
| Processor | 4309 (8-Core, 2.8 GHz, 105W)2 |
| Number of Processors | One processor with standard heatsink |
| Memory | 32 GB RDIMM 2R 3200 MT/s (1x 32 GB) |
| Network Controller | Broadcom BCM57412 Ethernet 10Gb 2-port SFP+ OCP3 Adapter for HPE Notes: No embedded networking |
| Storage Controller | MR416i-p/4GB with Smart Storage Battery |
| Hard Drive | None included |
| Optical Drive | Not included (Optical Drive options available) |
| PCIe Slots | 3 PCIe: x8/x16/x8 |
| Power Supply | 1x 800W Titanium |
| Fans | 6 - Maximum Performance |
| Management | HPE iLO 5 |
| Security | Notes: Disabled on AA1 SKUs |
| Rail Kit | Easy Install w/ CMA |
| Form Factor | 2U Rack |
.
